Hydroxy Ethyl Cellulose - Devasol - 300

Make an enquiry for this product

Description

DEVA SOL – 300 is a very high molecular weight HydroxyethylCe111ulose. It has been specially designed to produce clear viscous solution in hot and cold water based fluids with excellent shear thinning and suspending power abilities.

Application

DEVA SOL 300 is effective in all water based fluids, It has been studied to obtain the balanced dispersibility in drilling fluids thus allowing high effectiveness at very low damage. It can be used at any temperature, pH and viscosity of the drilling fluid.

Packaging

25 kg Bags, 50 kg Jumbo Bags as per customer requirement.

Properties

Viscosity

The apparent viscosity of DEVA SOL- 300 mixed with an aqueous solution increases rapidly with its concentration and irrespective of salinity, DEVA SOL- 300 yields high viscosity.

Shear Thinning

DEVA SOL- 300 provides excellent shear thinning thus ensuring optimum hole cleaning.

Fluid Loss

DEVA SOL- 300 possesses very good fluid loss control in suspended solids, oil soluble resins acid soluble agents.

Compatibility

DEVA SOL- 300 is non – iconic and hence a compatible polymer for work over/completion fluids and brines for oil industry.

Formation Damage

DEVA SOL- 300 has very low insoluble content and hence it avoids damage to formation.

Friction Reduction

DEVA SOL- 300 being a high molecular weight water soluble polymer; it reduces friction of fluids significantly during work over/ completion operations.

PH Stability

DEVA SOL- 300 maintains its viscosity in PH varying between 6 and 10 and its viscosity drops only in a highly acidic solution with a PH of 3 and below due to acid hydrolysis

Specifications

Sr. No. Property Units Results Obtained
1 Physical State - Free flowing powder, free from visible impurities
2 Dispersability of 0.7% (w/v) sample in fresh boiled and cooled distilled water in 45 mins @ 24±2°C - Highly dispersible
3 Moisture content @ 105±2°C %by mass 10.0(MAX)
4 Residue content (on dry basis) %by mass 0.5(MAX)
5 Performance Test: disperse 0.7%(w/v) of the material in 3.0% (w/v) solution of KCI in freshly boiled and cooled distilled water - -
A Viscosity@ 511sec-1 shear rate: - -
i After dispersion for 45 mins @24±20C cPs 50(MIN)
ii After aging for 48hrs @40±2°C cPs 45(MIN)
iii After aging for 2hrs @90±2°C cPs 20(MIN)
iv After aging for 2hrs @40±2°C by treating with 0.4% (v/v) of 15% (w/w) HCI cPs 5(MAX)
Sr. No. Property Units Results Obtained
B Flow Behavior index (n’) - -
i After dispersion for 45 mins@ 24±20C - 0.5 (MAX)
ii After aging for 48 hrs@ 40±2°C - 0.51(MAX)
iii After aging for 2 hrs@ 90±2°C - 0.55(MAX)
iv After aging for 2 hrs@ 90±2°C by treating with 0.4% (v/v) of 15%(w/w) HCI - MIN 0.99 - MAX 1.00

Safety Precautions

DEVA SOL-300 when dispersed in air, is highly inflammable. Hence care should be taken to minimize dust formation and complete avoidance of all avenues of ignition is mandatory. Spillage of DEVA SOL-300 should be cleaned mechanically as flooring can become slippery if it is subjected to water. We recommend users to wear masks in case they have a history of respiratory problems.

Customers are urged to ensure that the products are entirely suitable for their own purposes. Deva Drill Tech can frequently help in these technical matters, if required.
